1050 D32 Can Be Customized Water-cooling Tower Precision
Corrosion-resistant Aluminium Tubes
Product Description:
We provide 1 series of pure aluminum and 3 series of
corrosion-resistant aluminum tubes, and we can also customize
non-standard aluminum tubes for heat exchanger equipment according
to customers' needs. The main processing methods of aluminum alloy
include heat treatment, cold treatment, solution heat treatment,
aging treatment and annealing treatment.
Aluminum alloy is one of the most widely used non-ferrous metal
structural materials in the industry, which is widely used in
aerospace, automobile, machinery manufacturing, shipbuilding and
chemical industry.
Aluminum alloy has low density but relatively high strength,
approaching or exceeding high-quality steel, good plasticity, can
be processed into various profiles, has excellent electrical
conductivity, thermal conductivity and corrosion resistance, and is
widely used in industry.
Features:
We passivate and anticorrosive the inner and outer surfaces of
aluminum tubes, and add anticorrosive coatings on the inner and
outer surfaces, which is suitable for large heat exchange
equipment.
1050 aluminum alloy has good formability and surface smoothness,
and its corrosion resistance ranks among the best among all
aluminum alloys. Because it is pure aluminum, its strength is low,
and the higher the purity, the lower the strength.
We can provide technical support and services for the use of
aluminum pipes, including technical guidance and production
assistance. Our experienced technicians can help you solve any
problems you may encounter in the product.
Technical Parameters:
| Model Name | Model Number | Outside Diameter /mm | Wall Thickness/mm | Maximum Length/m | Length/mm | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm |
| Main Size | Series 1 | 20-32 | 0.8-2.0 | | 5000-15000 | | | |
| Series 3 |
| Example | 1050 | 35 | 1.8 | 18 | 9000 | 100~135 | ≥80 | ≥5.00 |
| 21 | 1.0 | 7000 |
| 31 | 1.5 | 6000 |
| 32 | 1.9 | 8000 |
1050
Applications:
power plant water cooling tower
surface condenser
large heat exchange equipment
condensator
evaporimeter
etc.
Support and Services:
The technical support and services for Air-conditioner and
refrigerator tubes include:
- Provide timely and accurate advice on product installation and
maintenance
- Provide technical support and solutions for repair and maintenance
- Provide after-sales service and maintenance for all products
- Provide professional advice and timely response to customer
inquiries
- Provide product training and technical advisory services
FAQ:
Q1: What kind of material alloy is the product?
A1: At present, it can produce 1 series industrial aluminum alloy,
3003 and 3103 aluminum manganese alloy.
Q2: What state and performance of the aluminum pipe can be
produced?
A2: can produce from hard state to soft state and interval
performance products
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements
can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
