Aluminum 3003 Aluminum Alloy 3 Series Aluminum Alloy H18 Silver
Product Description:
We supply aluminum alloy tubes for heat exchangers, which are made
of 3 series aluminum alloy, 1 series aluminum alloy, 6 series
aluminum alloy and 5 series aluminum alloy.
These products are mainly adopted by a wide range of air
conditioning, refrigerators, heat exchange and air conditioning
equipment manufacturers. We can offer a variety of shapes
(ruler-shaped or coil-shaped) and specifications of variety
selection. Each product has been produced by high-end
manufacturing, using advanced technology and professional heat
treatment technology for treatment, implementation of strict
production process control, high precision and low leakage rate,
good quality. Its extremely high induction density allows the
extruded tube to fully fit the channel requirements. In addition,
in line with the principle of customer-oriented, we will be in
accordance with the actual needs of customers, to provide the
corresponding specifications and performance characteristics of
customized services. The product comes from high-quality remelting
rod, strictly control the weight source, using large-tonnage
extruder, using hot extrusion cold drawing manufacturing method,
through multiple strict product quality testing procedures to
ensure product quality. I believe we can provide you with the best
quality products.
Features:
This aluminum alloy is widely used in many anti-rust materials,
because its strength is only slightly higher than industrial pure
aluminum and can not be enhanced by heat treatment characteristics,
so mainly cold processing to improve mechanical performance. It is
highly plastic in the annealed state; it remains good plasticity in
the just-undercooled processing stage; and it decreases in
plasticity after over-cooled processing. It has excellent corrosion
resistance and welding ability, but in the mechanical processing
performance is less.
Our company is strong and consists of an excellent technical team.
This team has accumulated a wealth of experience in
industrialisation. They have a close working relationship with a
number of well-known universities and research institutes such as
Xi'an Jiaotong University, Nankai University University and
Changzhou University, to jointly build a cutting-edge Innovation R
& D Laboratory.
Techical Parameters:
Heat Exchanger Aluminum Tube
The main production specifications are listed as follows:
| Model Number | State | Wall Thickness mm | Tensile Strength MPa | Non-proportional Elongation Strength MPa | Elongation After Break A50mm |
| 1050 1060 1070 1050A | O | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 |
| 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 |
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 |
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 |
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 |
The specifications in the form can be customized according to
customer's requirements.
Applications:
Condensator
Evaporimeter
Air-conditioning
Icebox
Home freezer
Industrial freezer
Cold storage with cold exhaust pipe
Small warm wind
Lipstick shell
Eyebrow pen shell
Air conditioning connection pipe
Car water tank connecting pipe
Car air-conditioning connection pipe
Microchannel heat exchanger connecting tube
etc.
Production Process:
Coil pipe
Raw material procurement-inspection-cleaning-extrusion-coiling-heat
treatment-flaw detection -forming-inspection-finished product
packaging
Stright pipe
Raw material
procurement-inspection-cleaning-extrusion-coiling-straightening-flaw
detection-fine cutting-cleaning-heat treatment-inspection-finished
product packaging
Support and Services:
We support and provide technical services for the use of aluminum
pipes and assist customers to solve the production problems arising
during the actual use process. Including the performance detection
of aluminum pipe, technical analysis, the use of the back channel,
aluminum pipe welding, aluminum pipe pipe, aluminum pipe bending,
finished product leakage detection, etc., at the same time in the
use of related problems, we will also assist customers to solve
problems in the first time. And make corresponding adjustments
according to the actual situation.
FAQ.:
Q1: What kind of material alloy is the product?
A1: Currently, there are 1 series, 3 series, and 6 series aluminum
alloy.
Q2: What state and performance of the aluminum pipe can be
produced?
A2: can produce from hard state to soft state and interval
performance products
Q3: Can I customize the product specifications and requirements?
A3: Different specifications and states can be customized according
to the requirements, such as fixed ruler straight pipe and coil
pipe
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
