Customized 3003 Grooved Aluminum Tubing Heat Transfer Arear 7mm

Ask Lasest Price
Brand Name :	Yun Neng
Model Number :	3003
Certification :	ISO9001 ISO4001 ISO45001
Price :	Negotiation
Payment Terms :	T/T
Supply Ability :	50,000 mt per year
Delivery Time :	30 working days after received your down payment

Add to Cart

Product Details
Company Profile

Customized 3003 Grooved Aluminum Tubing Heat Transfer Arear 7mm

3003 Aluminum Grooved Aluminum Tubing Heat Transfer Arear 7mm

Features:

As international copper prices continue to rise, and the instability of prices. Aluminum instead of copper seems to be a more economical option.

Technical Parameters:

Internal Thread Aluminum Tubing

Product Name	Model Number (Material)	State	SWAAT＞1000 h Tensile Strength 95-130 Mpa Yield Strength 50-80 Mpa Elongation≥32% Flare>40%
Product Name	Model Number (Material)	State	Outside Diameter/mm	Thickness/mm	Tooth Depth/mm	TWT/mm	Addendum Angle/(°)	Helix Angle/(°)	Number of Teeth	Shipping Methods
for example	3003	O	5-13	0.3-0.8	0.05-0.25	0.35-1.05	16-60	0-30	30-70	Coil
needs

The delivery method is coil or according to customer's requirements.

Technical requirements refer to national standards or customer technical quality requirements for production.

Applications:

condensator
evaporimeter
air conditioner external unit
Small heat exchanger
frigistor
packaged air conditioner
Dry wet machine
etc.

HOW TO ORDER

Customized 3003 Grooved Aluminum Tubing Heat Transfer Arear 7mm

Firstly,here is a more detailed product description about Internal Thread Aluminum Tubing.

Interal Threaded Tube-1.pdf

Inneral Thread Tube-2.pdf

You can then download a form from this website and fill it out with basic details.

Send it to the provided e-mail address, and our engineers will price you based on the technical specifications.

http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html

Alternatively, you can download the Technical Data Requirements Sheet directly.

Yuneng Product Requirements Table.docx
