Features:
3003 aluminum alloy for AL-Mn system alloy, is one of the most
widely used anti-corrosion aluminum, this alloy's strength is not
high (slightly higher than industrial pure aluminum), can not be
heat treatment to strengthen.
Therefore, the use of cold working methods to improve its
mechanical properties: high plasticity in the annealed state, in
the semi-cold hardening plasticity is still good, cold hardening
plasticity is low, good corrosion resistance, good weldability,
cutting performance is poor.
Applications:
Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
The 3xxx series aluminum alloy represents 3003, 3105 , 3A21 mainly.
The content is between 1.0 and 1.5, and it is a series with good
anti-rust function.
Commonly used for liquid products tanks, tanks, building processing
parts, construction tools, a variety of lamps and lanterns parts,
as well as thin plate processing of various pressure vessels and
pipelines. It has good molding, solubility, and corrosion
resistance.
| 1- Appearance | Aluminium tubes without defect, without blow on its surface,
without scratches, without pollution like grease or oil. |
| 2- Alloy Grade | 3003 |
3- Composition of alloy (%) Si Fe Cu Mn Zn Autres (others) |
0.60 0.70 0.05-0.20 1.0-1.5 0.10
|
Model Name |
Model Number | Outside Diameter /mm |
Wall Thickness/mm | Maximum Length/m | Length/mm | Tensile Strength /MPa | Non- proportional Elongation Strength /MPa | Elongation After Break A50/mm |
Main Size | Series 1, Series 3 | 20-32 | 0.8-2.0 | | 5000-15000 |
|
|
|
Example | 1050A | 28 | 1.0 | 18 | 7969 | 100~135
| ≥80 | ≥5.00 |
25 | 0.9 | 6959 |
23 | 1.5 | 9365 |
32 | 1.3 | 12266 |
H14 - tensile strength value corresponds to the intermediate value
between the annealed state O and the hard state, called 1/2 hard
state.
