3A21 aluminum alloy is one of the most widely used rust-proof
aluminum, the strength of this alloy is not high (slightly higher
than the industrial pure aluminum), can not be heat-treated to
strengthen, so it is used in cold-working methods to improve its
mechanical properties.
Features:
3A21 AL-Mn system alloy: in the annealed state has high plasticity,
in the semi-cold hardening plasticity is still good, cold hardening
plasticity is low, good corrosion resistance, good weldability,
cutting performance is bad. Uses are mainly used for the
requirements of high plasticity and good weldability.
Applications:
Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
The 3xxx series aluminum alloy represents 3003, 3105 , 3A21 mainly.
The content is between 1.0 and 1.5, and it is a series with good
anti-rust function.
Commonly used for liquid products tanks, tanks, building processing
parts, construction tools, a variety of lamps and lanterns parts,
as well as thin plate processing of various pressure vessels and
pipelines. It has good molding, solubility, and corrosion
resistance.
| 1- Appearance | Aluminium tubes without defect, without blow on its surface,
without scratches, without pollution like grease or oil. |
| 2- Alloy Grade | 3A21 |
3- Composition of alloy (%) Si Fe Cu Mn Mg Zn Ti Autres (others) |
0.60 0.70 0.20 1.0-1.6 0.05 0.15 0.10-0.20 |
Model Name |
Model Number | Outside Diameter /mm |
Wall Thickness/mm | Maximum Length/m | Length/mm | Tensile Strength /MPa | Non- proportional Elongation Strength /MPa | Elongation After Break A50/mm |
Main Size | Series 1, Series 3 | 20-32 | 0.8-2.0 | | 5000-15000 |
|
|
|
Example | 1050A | 28 | 1.0 | 18 | 7969 | 100~135
| ≥80 | ≥5.00 |
25 | 0.9 | 6959 |
23 | 1.5 | 9365 |
32 | 1.3 | 12266 |
H12 -- tensile strength value corresponds to the intermediate value
between the annealed state O and the 1/2 hard state, called the 1/4
hard state.
Main Product:
How to order:
You can then download a form from this website and fill it out with
basic details.
Send it to the provided e-mail address, and our engineers will
price you based on the technical specifications.
http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html
Alternatively, you can download the Technical Data Requirements
Sheet directly.
Yuneng
Product Requirements Table.docx
