Features:
3103 Aluminum tubes have excellent mechanical properties, good
malleability.
Suitable for processing into various shapes.
Corrosion resistance, the surface is easy to generate a layer of
dense oxide film, can effectively protect the internal not to be
corroded.
Strong electrical conductivity, commonly used in cable wire and
other electrical materials.
Extruded Aluminum Tubes
It is weaker in strength and structure than seamless aluminum
tubes, but it may be made at a lower cost because to its superior
production efficiency and comparatively lesser manufacturing
challenges.
In comparison to other comparable goods, processing flexibility and
longitudinal (extrusion direction) mechanical characteristics are
greatly improved.
Applications:
Large peak cooler
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
It is a series with good anti-rust function, and is commonly used
as tanks and tanks for liquid products, construction processing
parts, construction tools, various lamp parts, and various pressure
vessels and pipelines for thin plate processing. It has good
moldability, solubility, and corrosion resistance.
It is a series with good anti-rust function.
3xxx:
With the performance of 1xxx series alloy and to have a higher
strength than 1xxxx series alloy, such as kitchenware, food and
chemical products handling and storage devices, transportation of
liquid products tanks, tanks, as well as thin plate processing of
various pressure vessels and pipelines.
By the element manganese as the main component. The content is
between 1.0-1.5
| 1- Appearance | Aluminium tubes without defect, without blow on its surface,
without scratches, without pollution like grease or oil. |
| 2- Alloy Grade | 3103 |
3- Composition of alloy (%) Si Fe Cu Mn Mg Cr Zn Zr+Ti Autres (others) |
≤ 0.50 ≤ 0.70 ≤ 0.10 0.90 – 1.50 ≤ 0.30 ≤ 0.10 ≤ 0.20 ≤ 0.10 ≤ 0.15 |
Model Name |
Model Number | Outside Diameter /mm |
Wall Thickness/mm | Maximum Length/m | Length/mm | Tensile Strength /MPa | Non- proportional Elongation Strength /MPa | Elongation After Break A50/mm |
Main Size | Series 1, Series 3 | 20-32 | 0.8-2.0 | | 5000-15000 |
|
|
|
Example | 1050A | 28 | 1.0 | 18 | 7969 | 100~135
| ≥80 | ≥5.00 |
25 | 0.9 | 6959 |
23 | 1.5 | 9365 |
32 | 1.3 | 12266 |
H12 -- tensile strength value corresponds to the intermediate value
between the annealed state O and the 1/2 hard state, called the 1/4
hard state.
Main Product:
How to order:
You can then download a form from this website and fill it out with
basic details.
Send it to the provided e-mail address, and our engineers will
price you based on the technical specifications.
http://mao.ecer.com/test/al-tubes.com/cases/how-to-order-15643.html
Alternatively, you can download the Technical Data Requirements
Sheet directly.
Yuneng
Product Requirements Table.docx
