Grade 3103 H12 Aluminum Alloy For External Diameter 17.5 mm
Aluminum Tube Radiator
Indeed, the critical 3003 threaded inner tube supercharges
evaporative cooling in your home's central A/C unit. This
VITAL component of vapour heating condenses outdoor water via its
function. Essential for both residential / commercial air
conditioning heat exchange or elevated temperature pipes.
Our adaptability makes us a breeze to work with. We understand your
unique requirements are our priority.
Customization tailored to your exact specs is always an option. We
utilize cutting-edge tech and our robust quality control system
ensures top-notch aluminium tubes. Committed to offering you
superior, reliable goods.
http://mao.ecer.com/test/al-tubes.com/cases/power-plant-air-cooling-tube-product-pamphlet-15462.html
Features:
Discover our selection of internally threading aluminum tubes,
available in diverse tooth styles like thin-walled, high teeth, low
teeth, fine teeth, or small teeth. Let us know what you need, we'll
tailor the perfect tube for you!
These tubes, often known as dry steam, inner finned tubes, or inner
finned tubes, excel at heat exchange and see regular use in air
conditioning dry evaporators. Crafting involves both tension and
welding techniques.
Technical Parameters:
Internal Thread Aluminum Tubing
| Product Name | Model Number | State | SWAAT＞1000 h Tensile Strength 95-130 Mpa Yield Strength 50-80 Mpa
Elongation≥32% Flare>40% |
| (Material) | Outside Diameter/mm | Thickness/mm | Tooth Depth/mm | TWT/mm | Addendum Angle/(°) | Helix Angle/(°) | Number of Teeth | Shape |
| Main Size | 3003 | O | 5-13 | 0.3-0.8 | 0.05-0.25 | 0.35-1.05 | 16-60 | 0-30 | 30-70 | Coil |
| Example | Normal D7 | 3003 | | 7±0.05 | 0.47±0.03 | 0.25 | 0.97 | 18±5 | 18±2 | 50 |
| ECR D7 | 3003N | | 7±0.05 | 0.55±0.03 | 0.25 | 0.8 | 28±5 | 28±2 | 65 |
| ECR D5 | | 5±0.05 | 0.35±0.03 | 0.2 | 0.55 | 20±5 | 20±2 | 45 |
| ECR D7 | | 7±0.05 | 0.40±0.03 | 0.2 | 0.6 | 25±5 | 25±2 | 65 |
Applications:
condensator
evaporimeter
air conditioner external unit
Small heat exchanger
frigistor
packaged air conditioner
Dry wet machine
etc.
Support and Services:
We offer technical support and services related to thread aluminum
pipes, like production start-up, bend shaping, pipe elevating,
welding and other post-production aid. Experienced technicians are
on hand to resolve product issues. Regular after-sales care ensures
superior performance and satisfaction. Proud of our craftsmanship
and commitment to excellent customer service, we welcome all
inquiries and feedback.
