1070 D30 Aluminum Coil Tubing for Custom-made Heat Exchangers with
Anti-corrosion Coating
Product Description:
Features:
Both the interior and external surfaces of the anti-corrosion
coating of this product are coated with a particular anti-corrosion
alloy. The product's service life is significantly extended, the
corrosion-resistant test time exceeds 1000 hours, and the
corrosion-resistant effect is noticeably better than with the
standard aluminum alloy. Our organization produces products with
high density and excellent heat transfer efficiency through a
particular production technique. Using a large-tonnage extruder,
hot extrusion, and cold mode of production can offer a wide range
of state performance in terms of raw material quality control.
Among the product's attributes are its high density, small
tolerance, corrosion resistance, efficient heat transfer
performance, and high quality.
Applications:
Power plant water cooling tower
surface condenser
Large heat exchange equipment
condensator
evaporimeter
etc.
Technical Parameters:
1070 pure aluminum, high plasticity, corrosion resistance, good
electrical and thermal conductivity, suitable for aluminum foil
made of gaskets and capacitors.
| 1- Appearance | Aluminium tubes without defect, without blow on its surface,
without scratches, without pollution like grease or oil. |
| 2- Quality of aluminium alloy and treatment | AlMn extruded and calibrated Type 1070 |
3- Composition of alloy (%)
Fe Mg Mn Ti Al Autres (others) |
≤ 0.40 ≤ 0.05 ≤ 0.05 ≤ 0.05 99.50 ≤ 0.05 |
Aluminum Coil Tubing
| (Main Size) | State | Outside Diameter /mm | Wall Thickness /mm | Length /m | Tensile Strength /MPa | Non-proportional Elongation Strength /MPa | Elongation After Break A50/mm |
| Model Number |
| Main Size |
| Series 1 | 1050 1060 1070 1050A | O | 20-32 | 0.8-2.0 | 5-15 | ≤20.00 | 60~95 | ≥70 | ≥25.00 |
| H14 | ≤10.00 | 100~135 | ≥70 | ≥5.00 |
| Series 3 | 3003 3103 3A21 | O | ≤20.00 | 95~130 | ≥35 | ≥25.00 |
| H12 | ≤15.00 | 115~150 | ≥75 | ≥12.00 |
| H14,H24 | ≤10.00 | 135~165 | ≥110 | ≥6.00 |
| H28 | ≤3.00 | ≥180 | ≥145 | ≥3.00 |
Support and Services:
We can provide technical support and services for the use of
aluminum pipes, including technical guidance, production
assistance, etc. Our experienced technicians can assist you with
any problems your product may encounter. We also provide regular
after-sales service to ensure that your products are always run at
the highest efficiency. We are proud of our work and strive to
provide the best customer service.
If you have any questions or concerns about the product or your
use, please feel free to contact us. We will always give you the
answers you need.
FAQ:
Q1: What kind of material alloy is the product?
A1: At present, it can produce 1 series industrial aluminum alloy,
3003 and 3103 aluminum manganese alloy, and 6 series aluminum
alloy.
Q2: What state and performance of the aluminum pipe can be
produced?
A2: can produce from hard state to soft state and interval
performance products
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements
can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
