Heat Exchange Equipment Internally Threaded Pipe 3003 D7.94mm
Product Description:
3003 Efficient Corrosion Resistant internal thread aluminum tubing,
is a more reliable, more efficient heat transfer element, suitable
for the use of evaporator and condenser flow pipe in various
refrigeration equipment. The main medium used in the pipe is:
refrigerant, refrigerant, etc. The unique different threads and
high teeth in the inner table can greatly increase the heat
exchange area of products, reduce the use of refrigeration medium,
and optimize the cost.
The main production specifications are φ 9.52 φ 7.94 φ 7 φ 5 and
other finished products, and the specifications and performance
requirements can be customized according to customer requirements.
The inner wall of threaded pipe can be oil according to customer
requirements. To meet the requirements of the rear road rise pipe
process products. The product is made of aluminum alloy and looks
like silver. The final status of the product is: Coil Tube. Our
aluminum pipe from the raw material to each production process are
using strict control technology, in strict accordance with the
quality system management system. Provide the best quality and most
stable products.
Technical Parameters:
| Product Name | Model Number (Material) | State | SWAAT＞1000 h Ensile Strength＞130 Mpa Yield Strength 50-80 Mpa
Elongation≥35% Flare>40% |
| Outside Diameter/mm | Thickness/mm | Tooth Depth/mm | TWT/mm | Addendum Angle/(°) | Helix Angle/(°) | Number of Teeth/mm | Maximum Length/mm | Shape |
| Main Size | 3003 | O | 5-13 | 0.3-0.8 | 0.05-0.25 | 0.35-1.05 | 16-60 | 0-30 | 30-70 | | Coil |
| Example | | | 7 | 0.47 | +0.25 | 0.97 | | 18 | 40-50 | | |
| | 7 | 0.40 | +0.10 | 0.50 | | 40-50 | | |
| | 7.94 | 0.40 | +0.10 | 0.50 | | 40-60 | | |
| | 7.94 | 0.60 | +0.18 | 0.78 | | 40-60 | | |
| | | 9.52 | 0.45 | +0.05 | 0.50 | | 50-60 | | |
| | | 9.52 | 0.60 | +0.20 | 0.80 | | 50-60 | | |
Product specifications and performance requirements according to
the national standards or customer requirements.
Features:
More reliable and more efficient heat transfer components are
suitable for the evaporator and condenser in refrigeration and heat
transfer equipment with better performance, less refrigerant,
larger heat transfer area, better tooth shape, better spiral Angle,
higher heat exchange, lower cost. Can produce thin wall, high
tooth, low tooth, thin diameter, small tooth top angle, and custom
tooth shape products. Ultra-fine internal thread aluminum tube is
currently used in large numbers by foreign enterprises, domestic
leading enterprises such as Midea have begun to apply in batch. At
present, the main tube type specifications mainly focus on φ 7 and
develop to φ 5.
Applications:
Condensator
Evaporimeter
Air-conditioning
Icebox
Home freezer
Industrial freezer
Cold storage with cold exhaust pipe
Small warm wind
Lipstick shell
Eyebrow pen shell
Air conditioning connection pipe
Car water tank connecting pipe
Car air-conditioning connection pipe
Microchannel heat exchanger connecting tube
etc.
Support and Services:
We can provide technical support and services for the use of thread
aluminum pipes, including technical guidance for opening, bending,
pipe raising, welding and assistance in production, etc. We will
regularly communicate with customers about the use, according to
the use of timely adjustment, to ensure the customer production
efficiency and product quality.cooperation and mutual benefits
FAQ.:
Q1: What kind of material alloy is the product?
A1: two materials are available, 3003 anti-corrosion aluminum alloy
material and 30588 efficient anti-corrosion aluminum alloy
material.
Q2: Product final status?
A2: The final state of the product is soft aluminum coil, threaded
pipe inner surface can be coated with inner rising tube oil
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements
can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
