Air Conditioner Internal Threads Threaded Aluminum Tube ECR D5mm
Product Description:
Due to the increase of internal surface area of female threaded
aluminum tube, its thermal conductivity is twenty to thirty percent
higher than that of light tube. With the world's energy
constraints, aluminum instead of copper is gradually becoming the
trend, female threaded aluminum tubes are widely used in the air
conditioning and refrigeration industry.
Internal threaded aluminum tube has two main benefits:
1. Faster heat transfer, shorter cooling time.
2. greater heat transfer, due to the internal threads increase the
contact area of the refrigerant and the inner wall of the tube, the
refrigerant and the amount of tube contact is increased.
Applications:
condensator
evaporimeter
air conditioner external unit
Small heat exchanger
frigistor
packaged air conditioner
Dry wet machine,
etc.
Technical Parameters:
Efficient Corrosion Resistant
| Product Name | Model Number (Material) | State | SWAAT＞1000 h Tensile Strength 95-130 Mpa Yield Strength 50-80 Mpa
Elongation≥32% Flare>40% |
| Outside Diameter/mm | Thickness/mm | Tooth Depth/mm | TWT/mm | Addendum Angle/(°) | Helix Angle/(°) | Number of Teeth | Shape |
| Main Size | 3003 | O | 5-13 | 0.3-0.8 | 0.05-0.25 | 0.35-1.05 | 16-60 | 0-30 | 30-70 | Coil |
| Example | Normal D7 | 3003 | | 7±0.05 | 0.47±0.03 | +0.25 | 0.97 | 18±5 | 18±2 | 50 |
| ECR D7 | 3003N | | 7±0.05 | 0.55±0.03 | +0.25 | 0.80 | 28±5 | 28±2 | 65 |
| ECR D5 | | 5±0.05 | 0.35±0.03 | +0.20 | 0.55 | 20±5 | 20±2 | 45 |
| ECR D7 | | 7±0.05 | 0.40±0.03 | +0.20 | 0.60 | 25±5 | 25±2 | 65 |
Support and Services:
We can provide technical support and services for the use of thread
aluminum pipes, including the production of the opening, bending,
pipe raising, welding and other rear process technical guidance,
assistance in production, etc. Our experienced technicians can
assist you with any problems your product may encounter. We also
provide regular after-sales service to ensure that your products
are always run at the highest efficiency. We are proud of our work
and strive to provide the best customer service.
If you have any questions or concerns about the product or your
use, please feel free to contact us. We will always give you the
answers you need.
FAQ.:
Q1: What kind of material alloy is the product?
A1: two materials are available, 3003 anti-corrosion aluminum alloy
material and 30588 efficient anti-corrosion aluminum alloy
material.
Q2: Product final status?
A2: The final state of the product is soft aluminum coil, threaded
pipe inner surface can be coated with inner rising tube oil
Q3: Can I customize the product specifications and requirements?
A3: Different materials and products with different requirements
can be customized according to the requirements
Q 4: What is the minimum starting order volume?
A 4: The minimum order volume is 3 tons.
